EG4 FlexBOSS21™ All-in-One Inverter

SKU: EG4FLEXBOSS21
WarrantySpec SheetUser Manual

The EG4 FlexBOSS21 is an all-in-one, hybrind, sine inverter is a perfect choice for residential and smaller commercial applications. Made to work with the GridBOSS, the The EG4 FlexBOSS21 is a massive improvement over its cousin, the EG4 18kPV. Get the most out of your The EG4 FlexBOSS21 with full incorporation with the GridBOSS, however, the The EG4 FlexBOSS21 WILL work as a standalone unit.

Specifications:

  • Firmware Enhancements over the 18kPV Predessesor
  • Continuous Output Power – 12000VA
  • Peak Power – 16200VA for 1 min | 18000VA for 1s | 24000VA for 0.5s
  • 3 Separate MPPTs
  • Nominal Current 50A (AC Output)
  • Nominal Output Voltage 120/240V | 120/208V | 240V
    (AC Output)
  • Weight: 88lbs
  • Dimensions(HxWxD): 30.4×22.3×11.2 inches

$4,199.00

Log in to check member price

5 in stock (Accepting backorders for additional units.)

Description

The EG4 FlexBOSS21 is a 12/16 kW, 120/240 VAC split-phase, all-in-one, hybrid, sine wave inverter. It is ideal for residential applications and small business use. This versitile inverter can feed-through 90 Amps of utility power from the grid port to the load port. With a 21kW usable PV (DC) input, the FlexBOSS21 provides high power output and future expansion, generating 12 kW of AC power during non-sunlight conditions and a full 16 kW AC with solar PV gain. It is an enhancement on the 18kPV inverter, and is designed to work optimally with the GridBOSS power gateway. However, the EG4 FlexBOSS21 will work as a stand-alone inverter as your needs demand.

The EG4 FlexBOSS21 is the designed to work with the GridBOSS for full functionality. Full incorporation of the EG4 FlexBOSS21 and the GridBOSS eliminates component redundancy and reduces installation time, significantly reducing the cost of new and integrated systems. Together, they create a scalable system at a fair price, and keep your power infrastructure ready for growth without waste.

Features:

  • PV Inout – 21kW max useable PV | 24kW max PV input
  • On-Grid and Off-Grid capabilities
  • Three MMPTs configured as 26A/26A/15A
  • When coupled with GridBOSS: Supports AC Coupling, Smart Loads, and Generator
  • Continuous Power Output 16000W @ 240V | 13800W @ 208V (On-Grid AC Output)
  • Easily expandabile from minimal to large systems 50-160 Amps
  • Residential and Small Commercial
  • Compatible with EG4 batteries and other 48V battery systems
  • 10 Year Warranty

Recommended Accessories:

Additional information

Brand

EG4 Electronics
Battery Voltage

48 Volts DC
